Detailed Product Description
Extra thin wallmount kiosk with thermal receipt printer, PIN pad and card reader
Key Features
With thermal receipt printer, PIN pad and card reader
High-sensitivity, high light-transmittance, anti-glare, vandal-proof SAW touchscreen
15", 17", 19"TFT LCD displays for option
Durable steel enclosure, extra thin, stylish and floor space-saving design
Built-in hi-fi amplified speakers
Customization available upon request
Typical pplications: convenience store or other places where information and/or transaction are provided in self-service and interactive manner but floor space is at a premium.
|
Technical Specifications
|
|
TFT LCD Display
- Resolution: 1024x768(15")
1280x1024(17"and 19")
- Brightness: 250~300 nits
- Contrast ratio: 450:1
- Response time: 8 ms
|
Touch Screen
- Vandal-proof SAW touch screen
- Material: Heat tempered glass with thickness 6mm
- Resolution: 4096*4096
- Deviation of error: <2mm
- Light Transmittance: 92%
- Surface Hardness: 7 Mohs scale
- Lifetime:50, 000, 000 times at one single location
- Response time: less than 16 ms
- Touch activation force: 10~100g
|
Enclosure
- Durable steel enclosure (different colors for option)
- Built-in power control panel, and hi-fi speakers.
- Two cooling fans for computer board and main body separately
- RJ45/RJ11 interface
- Large access doors with tubular locks/keys
|
|
Mother Board
- Integrated display card/sound card/net card
- CPU: Intel Pentium dual core E5700, 3.6 GB (upgradeable on request)
- RAM: 2GB (upgradeable on request)
- Hard Disc: 500GB (upgradeable on request)
- Internet functionality
|
Compatible Operation System
LINUX/Win3.X/98/2000/NT4.0/XP
|
Working Voltage
AC 220V, 50 Hz or 110V, 60 Hz for option
|
|
Ambient Environment
- WorkingTemperature
-20°C~65°C;RelativeHumidity: 30%~90%
- Storage Temperature:
-40°C~80°C;Relative Humidity: 5%~95%
|
Weight and Dimensions
- Weight: 20 kgs for 19
- Dimensions: 45 x 65 x 15 cm(Width xHeight x Depth) for 19"
|
Peripherals
Thermal receipt printer, PIN pad and card reader
|
