Detailed Product Description
Rugged Stainless Steel, Water-proof Numeric Keypad with Integrated Optical Trackball
Key Features:
With integrated optical trackball
16 flush keys, crispy tactile feedback, 4 larger keys at the right column for function keys
Keys in 4 X 4 matrix
Panel mount, mounted from the rear side
Exposed parts made of stainless steel, high resistance against destruction, rust etc
Dust-proof and liquid-proof, IP65 compliance after properly mounted
Layout customizable according to customers request
Application: ATM, ADM, CDM, unattended payment terminals, vending machines, ticketing machines, gaming machines, kiosks, workstation etc.
Specifications:
Material:Front panel and keys:304 stainless steel;back panel:aluminum;trackball:stainless steel
Diameter of trackball:38mms
Resolution of trackball:1000dpi
Life cycle of keys: >5 million operations
Key travel: 0.45mm
Actuation force: 15015g
Interface: USB or PS2 for option
Working Temperature: -20°C~60°C
Storage Temperature: -40°C~80°C
Relative humility: 20~95%
Atmospheric pressure: 50-110 K Pa
Dimension:196.00 x 100.00 mm(L x W) (front panel)
