Industrial Keyboard With Trackball
>
103 Keys Trackball Rugged Metal Keyboard With Number Keys Function Keys

103 Keys Trackball Rugged Metal Keyboard With Number Keys Function Keys

Brand Name: KINGLEADER
Model Number: MKB-FN103A-TB
MOQ: 1pcs
Price: US$
Packaging Details: 1pcs/box, 10pcs/ctns
Payment Terms: T/T,Paypal
Detail Information
Place of Origin:
China
Certification:
CE,FCC
Material:
Stainless Steel
Number Of Keys:
103 Keys
Mounting Method:
Panel Mount From The Back Side
Mouse:
Trackball
Interface:
USB Or PS/2
Layout:
Standard US Layout Or Customized
Supply Ability:
2000pcs/month
Highlight:

103 Keys Rugged Metal Keyboard

,

Trackball Rugged Metal Keyboard

,

Function Keys Panel Mount Keyboard

Product Description



103 Keys Trackball Rugged Metal Keyboard With Number Keys , Function Keys



PN:MKB-FN103A-TB



Key Feature:

-103 keys(of them 10-12 function keys), panel mount

-Integrated trackball and numeric keypad;

-Protruding full travel(2.0mm)keys with etched engraved graphics, excellent tactile feedback

-Specially designed to operate in harsh environments, making it ideal for kiosks and other applications in public places.

-Built from stainless steel, high vandal-proof.

-Dust-proof and liquid-proof, meet IP65 requirement
-PS/2 or USB interface, easy to plug into computer directly
-Optical trackball or mechanical trackball for option
-Customizable

Specifications



Material

Front panel & Keys: Brushed stainless steel

Back panel: Aluminum alloy

Trackball: Stainless steel(Dia: 38mm)





Electrical Data

Power supply voltage: DC 5 V 5%

Current rating: 20 mA

Interface: USB or PS2

EMC compliant.
Emission: EN 50081-1
Immunity: EN 50082-1

FCC: Part 15, class B

Safety: EN 60950, CE compliant



Environmental Characteristics

Operating temperature: -20 C to + 60 C

Storage temperature: - 40 C to + 80 C

Saline mist: 96 hours, IEC 60512-6

Damp heat test at + 40 C: 21 days, IEC 60512-6

Dry heat test at + 85 C: 10 days, IEC 60512-6



Mechanical Data

Actuation force for key:120±15g

Key travel: 2.0mm

Lifetime (cycles): Min 5, 000, 000 actuations

Sealing protection: IP65/NEMA4X from the front

Vibration resistance: 5 Hz -200 Hz, IEC 60512-4

Shock resistance: 3 axis 150 m/s - 11 ms, IEC 60512-4

Operation system

PS2: Win NT4, 98SE, 98ME, 2000, XP

USB: Win 98SE, 98ME, 2000, XP, Mac OS9 / OSX



Weight and Dimension

Weight: 2.2kg

Dimension:
Front panel: 478.0 x 135.0 x 32.10mm
Back panel: 502.0 x 159.0 x 32.10mm(Mechanical track-ball)
Back panel: 502.0 x 159.0 x 49.10mm(Optical trackball)

103 Keys Trackball Rugged Metal Keyboard With Number Keys Function Keys 0

103 Keys Trackball Rugged Metal Keyboard With Number Keys Function Keys 1





FAQ

1. Q: How could I get samples?
A: If you need to order sample for checking-up, we would like to ask you to pay for the samples and courier freight. We send the samples to you only after receipt of your payment. If you have an courier account, you can send your courier to collect samples from our company or send us the samples charge together with the courier cost.
2. Q: How much the Courier freight will be for the samples?
A: Courier freight depends on the quantity, weight and carton size and your area.
3. Q: How can i get your price list?
A: Please leave your contact way Such as Email/MSN/Skype/ to us or click "Send Message”. We will contact to you and pass our quotation sheet to you.
4. Q: Can you arrange the transportation for us?
A: Yes, We can arrange transportation by sea or by air.
5. Q: What's your usual payment term for orders?
A: We accept terms of T/T /West Union/ PayPal/ LC/Credit Card
6. Q: What's the warranty of your products?
A: one year
Why us?

1, ISO9001:2008 certification
2, Audited supplier by SGS, TUV Rheinland and BUREAU VERITAS
3, Reasonable price and fast response
4, Over 10 years of experience in rugged input device and touch screen kiosk
5, OEM and ODM capability
6, Flexibility in customization and size of order
7, Trusted suppliers of many world-class famous brands in the industry

Our Services

* We’re a professional manufacturer for over 10 years.
* Experienced Technical Staffs and Patient, professional sales team.
* High quality assurance with competitive price
* OEM and ODM available.
* Any of your feedback will be responded within 12 hours
* Best after sales service to ensure satisfaction from customers.

How to order?

If you are interested in our products and want to place an order, firstly contact us by email, or contact with us online and we will send you our price list.

After that you can make a list of the products or just show the pictures that you are interested in and send it to us, so that we can prepare the Proforma Invoice with freight cost and bank account for your checking.

After you received the Proforma Invoice you can arrange payment using Western Union or Bank Transfer or PayPal.
Once we receive your full payment we prepare your goods and ship them out in 3-5 working days.

And we need to know the following information of your order:
a) Shipping information - Contact Name, Company name, Detail address, Phone number, Fax number,
b) Product information - model numbers, quantity, pictures
c) Delivery time required
d) Freight payment (by collect or prepare),or if you have own forwarder, tell us their contact details

Quality Check and Warranty:

We have a strict QC department in the factory, all raw material must be inspected before mass production.
Semi-product and final product must be checked very carefully on production line. Pick up defective ones and pack the good ones.

And we check our products one by one before we pack and ship to make sure they are all what you ordered, to make sure the quantity be in good condition.
We provide 1 year warranty. Please contact us whenever issues occur and we we’d try our best to assist.

Shipping terms:


1. Usual order: By express, DHL/ UPS/ FedEx etc. methods as you requested
2. Large order: By sea or By air

Payment terms:
Cash, Western Union, Bank Transfer(T/T), PayPal, Money Gra, Credit card

Main Markets:
North America; South America; Eastern Europe; Mid East; Eastern Asia; Western Europe; Central America; Northern Europe; Southern Europe
