Kiosk Industrial Stainless Steel Keyboard With Trackball

Place of Origin China
Brand Name KINGLEADER
Certification CE,FCC,ROHS
Model Number MKB-F86A-TB-2
Minimum Order Quantity 1pcs
Price US$
Packaging Details 1pcs/box, 10pcs/ctns
Delivery Time 20days
Payment Terms T/T,Paypal, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability 2000pcs/month
Product Details
Type Wired Keypad Button Material Metal
Material 304 Stainless Steel Interface Type USB,PS/2
Certification FCC,CE,ROHS Name Industrial Keyboard With Trackball
High Light

Kiosk Industrial Keyboard With Trackball

,

Kiosk Use Stainless Steel Keyboard

,

Stainless Steel Keyboard With Trackball

Leave a Message
Product Description

Industrial Keyboard Stainless Steel Metal Keyboard with Trackball Used for Kiosk



PN:MKB-F86A-TB



Application of industrial keyboard:

Specially designed to operate in harsh environments, making them ideal for kiosks and other applications in public places.



Specifications





Material

Front panel & Keys: Brushed stainless steel

Back panel: Aluminum alloy

Key cap: Protruding full travel key(2.0mm) with etched or laser engraved graphics

Trackball: Stainless steel trackball (Dia: 38mm)







Electrical Data

Power supply voltage: DC 5 V 5%

Current rating: 20mA

Interface: USB or PS2

EMC compliant.
Emission: EN 50081-1
Immunity: EN 50082-1

FCC: Part 15, class B

Safety: EN 60950, CE compliant



Environmental Characteristics

Operating temperature: -20 C to + 60 C

Storage temperature: - 40 C to + 80 C

Saline mist: 96 hours, IEC 60512-6

Damp heat test at + 40 C: 21 days, IEC 60512-6

Dry heat test at + 85 C: 10 days, IEC 60512-6





Mechanical Data

Actuation force for key:120±15g

Key travel: 2.0mm

Lifetime (cycles): Min 5, 000, 000 actuations

Sealing protection: IP65/NEMA4X from the front

Vibration resistance: 5 Hz -200 Hz, IEC 60512-4

Shock resistance: 3 axis 150 m/s - 11 ms, IEC 60512-4

Operation system

PS2: Win NT4, 98SE, 98ME, 2000, XP

USB: Win 98SE, 98ME, 2000, XP, Mac OS9 / OSX



Weight and Dimension

Weight: 2.2kg

Dimension:
Front panel: 392.00 x 135.00 x 32.10mm
Back panel: 416.00 x 159.00 x 32.10mm



Key Features of industrial keyboard:

- 86 keys( of them 12 function keys), panel mount
- Integrated trackball;
- Protruding full travel(2.0mm)keys with etched or laser engraved graphics, excellent tactile feel;
- Specially designed to operate in harsh environments, making them ideal for kiosks and other applications in public places
- Built from stainless steel, high vandal-proof.
- Dust-proof and liquid-proof, meet IP65 requirement
- PS/2 or USB connector, easy to plug into computer directly
- Customizable
